LRD10 TeSys Deca, thermal overload relay, 4 to 6 A, class 10A
LRD10 TeSys Deca, thermal overload relay, 4 to 6 A, class 10A Specification
- Phase
- 1
- Warranty
- 1 year
- Rated Voltage
- 110-215 Volt (V)
- Features
- Good Quality
- Feature
- Good Quality
- Shape
- Rectangualr
- IP Rating
- IP65 (Outdoor Rated)
- Surface Finish
- Smooth
- Product Type
- Thermal Overload Relays
- Protection Level
- IP54
- Size
- Standard
LRD10 TeSys Deca, thermal overload relay, 4 to 6 A, class 10A Trade Information
- Minimum Order Quantity
- 10 Pieces
- FOB Port
- INBOM4
- Payment Terms
- Cash Advance (CA), Cash in Advance (CID)
- Supply Ability
- 100 Pieces Per Week
- Delivery Time
- 10 Days
- Sample Available
- No
- Sample Policy
- If order is confirmed we will reimburse the sample cost
- Packaging Details
- BOX
- Main Export Market(s)
- Asia
About LRD10 TeSys Deca, thermal overload relay, 4 to 6 A, class 10A
| Range | TeSys TeSys Deca |
|---|---|
| Product name | TeSys LRD TeSys Deca |
| Product or Component Type | Differential thermal overload relay |
| Device short name | LRD |
| Relay application | Motor protection |
| Product Compatibility | LC1D09 LC1D32 LC1D38 LC1D12 LC1D18 LC1D25 |
| Network type | DC AC |
| Thermal overload class | Class 10A IEC 60947-4-1 |
| Thermal protection adjustment range | 46 A |
| [Ui] rated insulation voltage | Power circuit 600 V CSA Power circuit 600 V UL Power circuit 690 V IEC 60947-4-1 |
| Network Frequency | 0...400 Hz |
|---|---|
| Mounting support | Plate, with specific accessories Rail, with specific accessories Under contactor |
| Tripping threshold | 1.14 +/- 0.06 Ir IEC 60947-4-1 |
| Auxiliary contact composition | 1 NO + 1 NC |
| [Ith] conventional free air thermal current | 5 A signalling circuit |
| Permissible current | 3 A 120 V AC-15 signalling circuit 0.22 A 125 V DC-13 signalling circuit |
| [Ue] rated operational voltage | 690 V AC 0...400 Hz power circuit IEC 60947-4-1 |
| Associated fuse rating | 4 A gG for signalling circuit 4 A BS for signalling circuit |
| [Uimp] rated impulse withstand voltage | 6 kV |
| Phase failure sensitivity | Tripping current 130 % of Ir on two phase, the last one at 0 |
| Control type | Red push-button stop Blue push-button reset |
| Temperature compensation | -4140 F (-2060 C) |
| Connections - terminals | Control circuit screw clamp terminals 2 0.0020.004 in (12.5 mm) flexible without cable end Control circuit screw clamp terminals 2 0.0020.004 in (12.5 mm) flexible with cable end Control circuit screw clamp terminals 2 0.0020.004 in (12.5 mm) solid without cable end Power circuit screw clamp terminals 1 0.0020.02 in (1.510 mm) flexible without cable end Power circuit screw clamp terminals 1 0.0020.006 in (14 mm) flexible with cable end Power circuit screw clamp terminals 1 0.0020.009 in (16 mm) solid without cable end |
| Tightening torque | Control circuit 15.05 lbf.in (1.7 N.m) screw clamp terminals Power circuit 15.05 lbf.in (1.7 N.m) screw clamp terminals |
| Height | 2.6 in (66 mm) |
| Width | 1.8 in (45 mm) |
| Depth | 2.8 in (70 mm) |
| Net Weight | 0.273 lb(US) (0.124 kg) |
| Climatic withstand | IACS E10 |
|---|---|
| IP degree of protection | IP20 conforming to IEC 60529 |
| Ambient air temperature for operation | -4140 F (-2060 C) without derating IEC 60947-4-1 |
| Ambient Air Temperature for Storage | -76158 F (-6070 C) |
| Flame retardance | V1 conforming to UL 94 |
| Mechanical robustness | Vibrations6 Gn IEC 60068-2-6 Shocks15 Gn for 11 ms IEC 60068-2-7 |
| Dielectric strength | 1.89 kV 50 Hz IEC 60947-1 |
| Standards | EN/IEC 60947-4-1 EN/IEC 60947-5-1 UL 60947-4-1 UL 60947-5-1 CSA C22.2 No 60947-4-1 CSA C22.2 No 60947-5-1 GB/T 14048.4 GB/T 14048.5 EN 50495 |
| Product Certifications | IEC UL CSA CCC EAC BV RINA DNV-GL LROS (Lloyds register of shipping) ATEX INERIS UKCA |
| Category | US10I1222347 |
|---|---|
| Discount Schedule | 0I12 |
| GTIN | 3389110346794 |
| Returnability | Yes |
| Country of origin | FR |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 3.54 in (9.000 cm) |
| Package 1 Width | 2.83 in (7.200 cm) |
| Package 1 Length | 1.93 in (4.900 cm) |
| Package 1 Weight | 4.868 oz (138.000 g) |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 24 |
| Package 2 Height | 5.91 in (15.000 cm) |
| Package 2 Width | 11.81 in (30.000 cm) |
| Package 2 Length | 15.75 in (40.000 cm) |
| Package 2 Weight | 8.042 lb(US) (3.648 kg) |
| Warranty | 18 months |
|---|
